Puff Corn Flake Making Machine Large Capacity 500 - 1000 Kg/H
Basic Properties
Place of Origin:
China
Certification:
CE
Trading Properties
Minimum Order Quantity:
1-5set
Price:
7500-12000USD
Payment Terms:
T/T, D/P, D/A, L/C, Western Union
Supply Ability:
15-30sets/Month
Product Summary
Large capacity 500-1000 kg/h puff corn snack making machine corn flake making machine Product Description 1) Automatic Small corn flakes machinery corn flake making machine can use corn, rice, oat, other grain powder, and also some healthy nutritional ingredients like vitamin as raw materials to ...
Product Details
Highlight:
CE Puff Corn Making Machine
,1000 Kg/H Puff Corn Making Machine
,380V 50hz Corn Flake Making Machine
Name:
Large Capacity 500-1000 Kg/H Puff Corn Snack Making Machine Corn Flake Making Machine
Condition:
NEW
Voltage:
380V 50hz 3PHASE
After-Sales Service Provided:
Engineers Available To Service Machinery Overseas
Power(W):
30-150kw
Weight:
1500kg
Product Description
Large capacity 500-1000 kg/h puff corn snack making machine corn flake making machine
Product Description
1) Automatic Small corn flakes machinery corn flake making machine can use corn, rice, oat, other grain powder, and also some healthy nutritional ingredients like vitamin as raw materials to produce kinds of breakfast cereal snacks which can be eaten with milk as instant food.
2)After coated with sugar syrup or honey, the cereal will be tasted well and aet like leisure snacks directly. The breakfast cereal shapes are like ring, ball, star, stick, and others changed by different moulds.
3)Automatic Small corn flakes machinery corn flake making machine is muti-functional line which is the beat choice for clients.Corn Cereals Making Machine :
Flour Mixer → Screw Elevator → Double-screw Extruder →Elevator → Dryer →Elevator → Coating Line → Vibrating Spreader → Elevator →Dryer → Cooling Conveyor →packing machine
Product details
Double Screw Extruder Machine
Silk Road-75 Double Screw Extruder
serves to gelatinize flours and starches continuously and automatically.
After dosing, the materials are worked by two co-rotating screws composed by sectional modules for the following functions: forward and backward transport, mixing, de-gassing, cooking and forming.
Corn flakes press machine.
Material:- Stainless Steel Function:- Pressing Extruded pellets into flakes Separate Controller Box 1.it with big roller to press
2.it with cooling system 3.it can adjust the roller distance to adjust the flakes
2.it with cooling system 3.it can adjust the roller distance to adjust the flakes
thickness Power:16.12 kw
Size: 1550*1300*2000mm,
Roller:510* 310*1050mm
Roller:510* 310*1050mm
Mixer
Output:10-30kg/load Power:4kw
Tank Size: φ600 x500mm Dimention:1000*800*1200mm Flour
Mixer is used to mix the raw material, like
cornflour , rice flour, fish bone flour with liquid and other additives.
Stainless steel structure, the parts in contacting with the raw material or products, cover small area, easy cleaning and operate stably.
cornflour , rice flour, fish bone flour with liquid and other additives.
Stainless steel structure, the parts in contacting with the raw material or products, cover small area, easy cleaning and operate stably.
Screw conveyor
Driving Power: 0.75kw Dimension: 2700×500×2400mm Screw Conveyor
is used to convey the materials to the feeder of the extruder.
Stainless steel structure, especially the parts in contacting with the raw material or products; The materials is conveyed in a sealed stainless steel roller to the feeding hopper of extruder without leaking, dust pollution; Equipped with vibrating sifter to feed the materials stably and evenly; Easy cleaning and operation; run stably.
Stainless steel structure, especially the parts in contacting with the raw material or products; The materials is conveyed in a sealed stainless steel roller to the feeding hopper of extruder without leaking, dust pollution; Equipped with vibrating sifter to feed the materials stably and evenly; Easy cleaning and operation; run stably.
High-temperature Oven
Technical Parameter:
Size:4.5*1.4*1.8m
Power:3.75kw
Function: this high temperature oven is used to baking the corn flakes ,this oven we use gas for baking ,and there are both side
baking system ,can make the corn flakes more crisp.
Size:4.5*1.4*1.8m
Power:3.75kw
Function: this high temperature oven is used to baking the corn flakes ,this oven we use gas for baking ,and there are both side
baking system ,can make the corn flakes more crisp.
Sugar Spraying System
Technical Parameter:
Total Power: 28.75KW
Dimension: 4000×1900×1880mm
Roller Size: about Ø600 x 2700mm
Function: This machine consists of conveyor, melting tank and temperature keeping roller, and it is used to spray sugar on the
surface of the corn flakes.
Total Power: 28.75KW
Dimension: 4000×1900×1880mm
Roller Size: about Ø600 x 2700mm
Function: This machine consists of conveyor, melting tank and temperature keeping roller, and it is used to spray sugar on the
surface of the corn flakes.
product show
Corn flakes being one of most nutritious foods and is consumed as breakfast food not only in China but-elsewhere in the world. Basically, it is prepared from maize; this is the main raw material. Flavours, like sugar or salt are also added. Maize, the main raw material, is itself a corn grain. Corn flakes have very good taste. Though several other breakfast cereals are also available in the market but they are still to gain popularity.
