100-2000kg Capacity Modified Starch Machine Stainless Steel

100-2000kg Capacity Modified Starch Machine Stainless Steel
100-2000kg Capacity Modified Starch Machine Stainless Steel
100-2000kg Capacity Modified Starch Machine Stainless Steel 100-2000kg Capacity Modified Starch Machine Stainless Steel 100-2000kg Capacity Modified Starch Machine Stainless Steel

Large Image :  100-2000kg Capacity Modified Starch Machine Stainless Steel

Product Details:
Place of Origin: CHINA SHANDONG
Brand Name: MT
Certification: CE
Model Number: MT 65 70 85
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD 28000-35000 SET
Packaging Details: PLASTAIC FILM PACKING
Delivery Time: 30-45 WORK DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 1 SET MONTH

100-2000kg Capacity Modified Starch Machine Stainless Steel

Description
Product Name: Stainless Steel Modified Starch Pregelatinized Starch Oil Drilling Starch Machine Materials: Stainless Steel 201 / 304
Raw Material: Cassava Starch Capacity: 100-2000kg
After-sales Service Provided: Oversea Service Inverter: Delta,Customizable
High Light:

2000kg capacity modified starch machine

,

100kg capacity modified starch machine

,

stainless steel modified starch machine

Stainless steel Modified starch Pregelatinized starch oil drilling starch machine





Product Description of Stainless Steel Modified Starch Pregelatinized Starch Oil Drilling Starch Machine:

100-2000kg Capacity Modified Starch Machine Stainless Steel 0



Pre-gelatinized starch/Modified starch extrusion machine can product Denatured Starch, Pre-gelatinized starch is an effective and economical fluid loss agent in water based drilling fluids, which is a starch derivative. It is not bacterial degradation when at 120°C, environmentally acceptable and non-toxic. Modified Starch can produce a thin, slick, tough filter cake and promotes faster penetration rates with reducer friction. It can be used in all kinds of drilling fluid system. Pre-gelatinized starch is also sometimes "pregelatinized" to make them easier to dissolve during product manufacture. Modified starch is widely used in oil drilling, textile, paper and food industries



Advantages of Stainless Steel Modified Starch Pregelatinized Starch Oil Drilling Starch Machine:

1. The motor of our extruder machine is Siemens Motor.

2. The raw material of our machines is Stainless Steel.

3. Our automatic machines are controled by frequency changer, it is easy to operate.

4. Our factory will send our engineer to install machines for you.

5. Baked snack machine have the 12 months guarantee time.

6. The machine is multifunction. Many types of snacks can be manufactured by changing the die head and model.



Technical parameter of Stainless Steel Modified Starch Pregelatinized Starch Oil Drilling Starch Machine:

Model Installed power Real power output Dimension
MT65 66kw 50kw 100-150kg/h 19000x1200x2200mm
MT70 100kw 67kw 200-240kg/h 21000x1500x2200mm
MT85 130kw 80kw 400-500kg/h 30000x3500x4300mm


Flow chart of Stainless Steel Modified Starch Pregelatinized Starch Oil Drilling Starch Machine :

Mixer→Screw Conveyor→ Twin Screw Extruder→ Air Conveyor→ Multi-layer Dryer→ Cooling Conveyor→Air Conveyor→Milling Machine

Machine details of Stainless Steel Modified Starch Pregelatinized Starch Oil Drilling Starch Machine:

100-2000kg Capacity Modified Starch Machine Stainless Steel 1
Power:

4kw
Output :
20-30kg/times
Size:
1.0*0.8*1.2m
Functions:
To mix the raw materials such as corn flour with some additives.
To touch the food is SS
100-2000kg Capacity Modified Starch Machine Stainless Steel 2
Feeding power:
0.75kw
Feeding screw diameter:
55mm
Feed Screw Speed:
0-150rpm
Main Motor Power:
22kw
Main Screw Length:
1050mm
Functions:
To extrude and inflate the food.the main machine of the line
100-2000kg Capacity Modified Starch Machine Stainless Steel 3

Dryer

Adjustable door hinge; flat laying mesh belt; tailor-made materials receiver Heating method: gas/electric/steam/diesel Air consumption: 15-25m³/h
Size:5500*1200*2300mm
Power:1.1kw Functions:To dry the snack food for the good baby power
100-2000kg Capacity Modified Starch Machine Stainless Steel 4

Crusher

Motor Power :7.5kw Vacuum motor:5.5kw Discharge power:0.75kw

Size:7.2*1.3*2.9m
Capacity:100-150kg/h
Functions:The cush the snack food with the dedusting system



100-2000kg Capacity Modified Starch Machine Stainless Steel 5
100-2000kg Capacity Modified Starch Machine Stainless Steel 6

100-2000kg Capacity Modified Starch Machine Stainless Steel 7


100-2000kg Capacity Modified Starch Machine Stainless Steel 8
100-2000kg Capacity Modified Starch Machine Stainless Steel 9


100-2000kg Capacity Modified Starch Machine Stainless Steel 10

We can provide the electronic edition certificates for Stainless Steel Modified Starch Pregelatinized Starch Oil Drilling Starch Machine, if asked, or you can see the original documents in our factory. We can ensure the truth of our certificates.

100-2000kg Capacity Modified Starch Machine Stainless Steel 11



1. Pre-sale services:

Act as a good adviser and assistant of clients, enable them to get rich and generous returns on their investments

1.. Select equipment model;

2.. Design and manufacture products according to clients' special requirement;

3.. Train technical personnel for clients.

2. Services during the sale:

Respect clients, devote ourselves to improving the total value of clients.

1.. Pre-check and accept products ahead of delivery;

2.. Help clients to draft solving plans.

3. After-sale services:

Provide considerate services to minimize clients' worries.

1.. Assist clients to prepare for the first construction scheme;

2.. Install and debug the equipment;

3.. Train the first-line operators;

4.. Examine the equipment;

5.. Take initiative to eliminate the troubles rapidly;

6.. Provide perfect service;

7.. Provide technical exchanging.

100-2000kg Capacity Modified Starch Machine Stainless Steel 12

1. Q: Are you a factory or trading company?

A: We are a factory.


2. Q: What certificate do you have?
A: We have ISO and CE certificate.


3. Q: How long is the warranty period?
A: All of our products have one year warranty.

4. Q: What's the main market of your company?
A: We have customers all over the world.


5. Q: How much production capacity of your company one year?
A: This depends on your needs.

6. Q: Where is your factory located? How can we visit there?
A:
Hu Guan Tun Zhen Zhuowei Machinery Park, Qihe County, Dezhou City, Shandong Province
